Affordable Desktop CO2 Laser Marking Machine
M06 series desktop CO2 laser marking machine is designed with a convenient pulley device, which allows the equipment to be easily transferred between different work locations. The specially designed drawer not only adds extra storage space for storing various tools, accessories and materials, but also helps to maintain a clean and orderly working environment. This model supports different power options of 30W, 40W and 60W to meet diverse marking needs; its marking area covers a range from 100mm to 500mm (optional), meeting marking tasks of various sizes. In addition, it is equipped with a high-performance galvanometer system to ensure high precision and efficiency during the marking process, and can easily handle both delicate patterns and large-area markings.
- • Laser power: 30w, 40w, 60w
- • Beam diameter: <1.2mm
- • Minimum line width: 0.01~0.1mm
- • Wavelength: 10.6um
- • Processed materials: various non-metallic materials such as wood, acrylic, glass, textiles, leather, and certain plastics.
- Information
- Specification
- Video
| Item | M06-30 | M06-40 | M06-60 |
| Supply voltage | 110v/220v, 50/60Hz | 110v/220v, 50/60Hz | 110v/220v, 50/60Hz |
| Overall power consumption | <1000w | <1000w | <1000w |
| Cooling method | Air cooling | Air cooling | Air cooling |
| Laser output power | 30w | 40w | 60w |
| Laser light source | DAVI/ CRD/ HAN's | DAVI/ CRD/ HAN's | DAVI/ CRD/ HAN's |
| Laser wavelength | 10.6um | 10.6um | 10.6um |
| Beam diameter | <1.2mm | <1.2mm | <1.2mm |
| Marking area | 100*100~200*200mm | 100*100~300*300mm | 100*100~500*500mm |
| Minimum line width | 0.01~0.1mm | 0.01~0.1mm | 0.01~0.1mm |
| Minimum character | 0.5mm | 0.5mm | 0.5mm |
| Marking depth | 0.1~0.5mm | 0.1~2mm | 0.1~4mm |
| Max. marking speed | 7000mm/s | 7000mm/s | 7000mm/s |
| Cable length | 1.5m (cable length and plugs can be customized) | 1.5m (cable length and plugs can be customized) | 1.5m (cable length and plugs can be customized) |
| Working environment | -10℃~40℃ | -10℃~40℃ | -10℃~40℃ |
| Weight | About 75kg | About 75kg | About 75kg |
Suitable for marking needs of diverse materials: M06 desktop CO₂ laser marking equipment performs well in the processing of non-metallic materials. It can be widely used for fine engraving and marking on wood, acrylic, glass, cloth, leather and various plastic surfaces. It has strong adaptability and clear and lasting effects.
Accurately present various graphic contents: equipped with a high-precision optical galvanometer system, M06 can easily cope with the engraving tasks of complex patterns, corporate logos, text layouts and even photos and other diverse image contents, and achieve delicate and realistic marking effects on different materials.
Stable and efficient professional-level marking experience: as a reliable CO₂ laser marking machine, it not only has excellent operating stability, but also can maintain fast response and high efficiency during long-term work, taking into account high-quality output and production rhythm, and is suitable for a variety of industrial and creative processing scenarios.
Support multi-dimensional parameter control: the desktop CO₂ marking machine is equipped with an intelligent control platform, and the operator can flexibly adjust the operating parameters according to needs, including processing speed, laser power and pulse frequency. This multi-dimensional parameter control capability makes the marking depth and forming effect more accurate and controllable, meeting the diverse requirements of different materials and processes for precision.
M06 desktop CO₂ laser marking machine is widely used in packaging, textiles, advertising gifts, electronic manufacturing and other industries. It mainly performs efficient and accurate marking on non-metallic materials such as wood products, bamboo, leather, rubber, fabric, paper, ceramics, stone, acrylic, etc. It is suitable for product packaging marking, architectural decorative ceramic lettering, clothing accessories processing, shoe accessories, handbag components, eyeglass frames, fabric pattern engraving, handicraft decoration, rubber product numbering, electronic equipment shell marking, nameplate marking and stone art engraving and other application scenarios to meet the fine marking needs of diversified industries.
